TYL precision filter
product name: TYL precision filter
Product number:SN20170829175544223
Update time:2017-08-29
Supply business home:
Views: 1101
The series of products is mainly to remove compressed air in the oil, water, dust. The series of products with small size, high efficiency, easy to use, the characteristics of small pressure. Filtration accuracy can be divided into C, T, A three. C grade filtration accuracy ≤ 3μm, remove 99.9% free state of oil, water; T-class filtration accuracy ≤ 1μm, remove 99.99% free state of oil, water; A-class filtration accuracy ≤ 0.01μm, remove 99.999 % Of the free state of oil, water, so that effective gas purification.
Working pressure: 0.6 ~ 1.0Mpa (according to the requirements of 1.0 ~ 4.0Mpa)
Intake air temperature: ≤ 45 ℃
Resistance drop: ≤ 0.015Mpa
